SRAM Force 22 GXP Chainset
SRAM Force 22 GXP Chainset
Combining carbon fibre with forged aluminium, the SRAM Force 22 GXP Compact Chainset AU offers the ideal mix of stiffness and low weight. It also boasts X-GlideR chainrings to bring you fast and slick gear changes.
The stunning X Glide R™ chainrings on the SRAM Force 22 chainset are optimised for use with the YAW™ Technology in the front derailleur, delivering a seamless, flawless performance. These stiffer rings are made with 5mm thick CNC-machined 7075-T6 aluminium and feature upshift rivets with an advanced design adopted from SRAM XX. CNC machining allows for precision control of each tooth shape, ramp, and nearly every shifting feature of the chainring. The chainrings, chain, and front derailleur in the Force 22 range are all designed as a single integrated system for optimised performance.
Exogram™: The revised Hollow Carbon Construction starts in the crank arm and extends into the cranks’ spider. It maximises the stiffness-to-weight ratio
- Arm Material: Carbon w/ Machined Alloy spider
- Chainring Material: Machined Alloy (X-GlideR™ Chainrings Included)
- Teeth: 53/39t
- Crank arm length: 175mm
- Bolt Circle Diameter: 110mm - hidden bolt pattern
- Bolts: Alloy Double Hex
- Speed: 2x11-Speed
- Compatible with all SRAM 2x11-Speed road drivetrains
- Compatibility: SRAM RED 22 and Force 22 Yaw™ Front Derailleurs, SRAM RED 22 & PC1170 chains
- Bottom Bracket Compatibility: GXP (sold separately)
- Axle: 24-22mm GXP spindle
- Part No: 00.6118.108.003
- Weight: 715g
